Chapter 17 Configuring Dynamic Subscriber Services
Applying Traffic Shaping Parameters Using RADIUS Profiles
Enabling Dynamic Bandwidth Selection on a PVC Within a PVC Range
To enable dynamic bandwidth selection on a specific PVC within a range of PVCs, enter the following
commands beginning in global configuration mode:
Command Purpose
Step 1
Router(config)# interface atm
slot/module/port.subinterface [point-to-point |
multipoint]
Specifies the ATM interface or subinterface. Enters
interface or subinterface configuration mode.
Step 2
Router(config-if)# range [range-name] pvc
start-vpi/start-vci end-vpi/end-vci
Defines a range of ATM PVCs and enters ATM range
configuration mode.
range-name is the name of the range. The range-name can
have up to 15 characters.
start-vpi/ is the beginning value for a range of virtual path
identifiers (VPIs). If you do not specify a vpi value, the vpi
value defaults to 0. Valid values are from 0 to 255. The
slash is required.
start-vci is the beginning value for a range of virtual
channel identifiers (VCIs). Valid values are from 32 to
65535.
end-vpi/ is the end value for a range of VPIs. If you do not
specify an end-vpi value, the value defaults to the start-vpi
value. Valid values are from 0 to 255. The slash is required.
end-vci is the end value for a range of VCIs. Valid values
are from 32 to 65535.
Step 3
Router(config-if-atm-range)# pvc-in-range
[pvc-name] [vpi/vci]
Defines an individual PVC within a PVC range. Enters
PVC-in-range configuration mode.
pvc-name is the name of the PVC. The pvc-name can have
up to 15 characters.
vpi/ is the virtual path identifier for the PVC. If you do not
specify a vpi value, the vpi value defaults to 0. Valid values
are from 0 to 255. The slash is required.
vci is the virtual channel identifier for the PVC. Valid
values are from 32 to 2047.
Step 4
Router(config-if-atm-range-pvc)# dbs enable
Enables dynamic bandwidth selection and allows the traffic
shaping parameters retrieved from RADIUS to be applied
to the PVC in the range of PVCs.
