17-49
Cisco 10000 Series Router Quality of Service Configuration Guide
OL-7433-09
Chapter 17 Configuring Dynamic Subscriber Services
Shaping and Queuing Per-Session Traffic on LNS
Configuration Example for Configuring a Per Session Shaping and Queuing on LNS Policy
Example 17-27 shows how to configure a per session shaping and queuing on LNS policy. In this
example, the router uses 20 overhead bytes and ATM cell tax in calculating ATM overhead. The child
and parent policies contain the required matching offset values. The parent policy is attached to virtual
template 1.
Example 17-27 Configuring Per Session Shaping and Queuing on LNS Policy on the Router
policy-map child
class class1
bandwidth 500 account user-defined 20 atm
class class2
shape average 30000 account user-defined 20 atm
policy-map parent
class class-default
shape average 30000 account user-defined 20 atm
service-policy child
interface virtual-template 1
service-policy output parent
Verifying Per Session Shaping and Queuing on LNS Policies
To display the configuration of per session shaping and queuing on LNS policies, enter the following
commands in privileged EXEC mode:
Command Purpose
Router# show policy-map [policy-map]
Displays the configuration of all classes for a specified service
policy map or all classes for all existing policy maps.
policy-map specifies the name of the policy map.
Router# show running-config
Displays the running configuration on the router. The output
shows the configuration of the policy maps.
