Procedure
Step 1
Access Cisco Unified Communications Manager Administration.
Step 2
To configure softkey templates, select Device > Device Settings > Softkey Template.
Step 3
To assign a softkey template to a phone, select Device > Phone and configure the Softkey Template field.
Set Up Separate Audio and Video Mute
You can control the ability of your users to mute the audio on a call.
Procedure
Step 1
In Cisco Unified Communications Manager Administration, select System > Enterprise Phone Configuration.
Step 2
To enable the feature, set the Separate Audio and Video parameter to Enabled.
Step 3
Select Save.
Set Up RTP/sRTP Port Range
You configure the Real-Time Transport Protocol (RTP) and secure Real-Time Transport Protocol (sRTP)
port values in the SIP profile. RTP and sRTP port values range from 2048 to 65535, with a default range of
16384 to 32764. Some port values within the RTP and sRTP port range are designated for other phone services.
You cannot configure these ports for RTP and sRTP.
For more information, see SIP Profile information in the documentation for your particular Cisco Unified
Communications Manager release.
Procedure
Step 1
Select Device > Device Settings > SIP Profile
Step 2
Choose the search criteria to use and click Find.
Step 3
Select the profile to modify.
Step 4
Set the Start Media Port and Stop Media Port to contain the start and end of the port range.
The following list identifies the UDP ports that are used for other phone services and thus not available for
RTP and sRTP use:
port 4051
used for the Peer Firmware Sharing (PFS) feature
port 5060
used for SIP over UDP transport
Cisco Unified IP Phone 8961, 9951, and 9971 Administration Guide for Cisco Unified Communications Manager 10.0
241
