For more information about AP channel and domain relationships, see Cisco Unified IP Phone 9971 Wireless
LAN Deployment Guide at this location:
http://www.cisco.com/en/US/products/ps10453/products_implementation_design_guides_list.html
The AP uses the connection to the wired network to transmit data and voice packets to and from the switches
and routers. Voice signaling is transmitted to the Cisco Unified Communications Manager server for call
processing and routing.
Cisco requires that APs that support voice communications use Cisco IOS Release 12.3(8)JA or later. Cisco
IOS software provides features for managing voice traffic. In some WLANs, each AP has a wired connection
to an Ethernet switch, such as a Cisco Catalyst 3750, that is configured on a LAN. The switch provides access
to gateways and the Cisco Unified Communications Manager server to support wireless IP telephony.
The wireless Cisco Unified IP Phone 9971 is supported on both the Cisco autonomous and unified solutions
support the following access points:
Minimum and recommended versions are:
•
Cisco IOS Access Points (Autonomous)
◦
Minimum = 12.3(8)JEA2 or later
◦
Recommended = 12.4(10b)JA3 or later (Does not apply to Cisco Aironet Series 1100, 1140, 1200,
or 1230)
•
Cisco Unified Wireless LAN Controller
◦
Minimum = 5.1.163.0 or later
◦
Recommended = 5.2.193.0 or later
The following table lists the modes that each Cisco Access Point supports.
Table 7: Supported APs and Modes
Unified ModeAutonomous
Mode
802.11a802.11g802.11bAP Models
YesYesNoYesYesCisco Aironet 500 Series
YesYesNoYesYesCisco Aironet 1100 Series
YesYesYesYesYesCisco Aironet 1130 AG Series
YesYesYesYesYesCisco Aironet 1140 Series
YesYesOptionalYesYesCisco Aironet 1200 Series
YesYesYesYesYesCisco Aironet 1230 AG Series
YesYesYesYesYesCisco Aironet 1240 AG Series
YesYesYesYesYesCisco Aironet 1250 Series
YesYesNoYesYesCisco Aironet 1300 Series
Cisco Unified IP Phone 8961, 9951, and 9971 Administration Guide for Cisco Unified Communications Manager 10.0
45
VoIP Wireless Network Components

Cisco 9971 Specifications

General

Resolution	640 x 480 pixels
Programmable Line Keys	5
Protocols	SIP, SCCP
Wi-Fi	802.11a/b/g
Weight	3.5 lbs
Display	5-inch color LCD
Audio	Wideband audio, G.722 codec support
USB Ports	2 x USB 2.0
Ethernet Ports	2
PoE	Yes (802.3af)
Video	H.264
Network Interfaces	10/100/1000 Ethernet
Codecs	G.711, G.722, G.729a, G.729ab, iLBC
Power Options	PoE
Headset Port	Dedicated headset port
Speakerphone	Full-duplex speakerphone
