Step 3
To exit the Model Information screen, press Exit.
Related Topics
Cisco IP Phone Web Page, on page 284
Model Information Fields
The following table describes the Model Information settings.
Table 34: Model Information Settings
DescriptionOption
Model number of the phone.Model Number
IP address of the phone. The address displayed depends on the IPv6 setup.IPv4 Address or IPv6
address
Host name of the phone.Host name
Version of firmware currently installed on the phone. The user can press Details
for more information.
Active Load
Inactive Load appears only when a download is in progress. A download icon
and a status of “Upgrade in Progress” or “Upgrade Failed” also display. If a user
presses Details during an upgrade, the download filename and components are
listed.
A new firmware image can be set to download in advance of a maintenance
window. Thus instead of waiting for all of the phones to download the firmware,
the system switches more rapidly between resetting an existing load to Inactive
status and installing the new load.
When the download is complete, the icon changes to indicate the completed
status; and a check mark displays for a successful download, or an “X” displays
for a failed download. If possible, the rest of the loads continue to download.
Inactive Load
Date of the most recent firmware upgrade.Last Upgrade
Domain name of the server to which the phone is registered.Active Server
Domain name of the standby server.Stand-by Server
Display Status Menu
The Status menu includes the following options, which provide information about the phone and phone
operations:
Cisco Unified IP Phone 8961, 9951, and 9971 Administration Guide for Cisco Unified Communications Manager
10.0
264
Cisco Unified IP Phone Status
