DescriptionItem
Host names or IP addresses, in prioritized order, of the Cisco Unified Communications
Manager servers with which the phone can register. An item can also show the IP
address of an SRST router that is capable of providing limited Cisco Unified
Communications Manager functionality, if such a router is available.
For an available server, an item shows the Cisco Unified Communications Manager
server IP address and one of the following states:
•
Active: Cisco Unified Communications Manager server from which the phone
is currently receiving call-processing services
•
Standby: Cisco Unified Communications Manager server to which the phone
switches if the current server becomes unavailable
•
Blank: No current connection to this Cisco Unified Communications Manager
server
An item may also include the Survivable Remote Site Telephony (SRST) designation,
which identifies an SRST router capable of providing Cisco Unified Communications
Manager functionality with a limited feature set. This router assumes control of call
processing if all other Cisco Unified Communications Manager servers become
unreachable. The SRST Cisco Unified Communications Manager always appears
last in the list of servers, even if it is active. You configure the SRST router address
in the Device Pool section in Cisco Unified Communications Manager Configuration
window.
Unified CM
URL of the help text that appears on the phone.Information URL
URL of the server from which the phone obtains directory information.Directories URL
URL of the server from which the phone obtains message services.Messages URL
URL of the server from which the phone obtains Cisco Unified IP Phone services.Services URL
Indicates whether the phone uses DHCP.DHCP Enabled
Indicates the setting of the DHCP Address Released option on the phone Network
Configuration menu.
DHCP Address
Released
Indicates whether the phone is using an alternative TFTP server.Alternate TFTP
URL that the phone displays when the phone is idle for the time that the Idle URL
Time field specifies and no menu is open.
Idle URL
Number of seconds that the phone is idle and no menu is open before the XML service
that the Idle URL specifies activates.
Idle URL Time
URL of proxy server, which makes HTTP requests to nonlocal host addresses on
behalf of the phone HTTP client and provides responses from the nonlocal host to
the phone HTTP client.
Proxy Server URL
Cisco Unified IP Phone 8961, 9951, and 9971 Administration Guide for Cisco Unified Communications Manager
10.0
288
Cisco IP Phone Web Page
