Cisco SGE2000 - Cisco - Gigabit Switch Administration Guide

Configuring IP Information
IP Addressing
Cisco Small Business SFE/SGE Managed Switches Administration Guide 192
7
STEP 1 Click System > System Management > IP Addressing > IPv6 Configuration > IPv6
Interface . The IPv6 Interface Page opens:
IPv6 Interface Page
The IPv6 Interface Page contains the following fields:
• Interface — Indicates the Link Local Interface. The possible field values are:
- VLAN — Indicates VLAN is the Link Local interface.
- ISATAP Tunnel — Indicates a ISATAP tunnel is a Link Local interface.
• IPv6 Type — Displays the IPv6 Type. The possible field values are:
- Link-Local — Indicates the IPv6 address is link-local.
- Global Unicast — Indicates the IPv6 address is global Unicast.
• IPv6 Address — Indicates the IPv6 address assigned to the interface. Up to
five IP addresses can be set per interface, with the limitation that up to 128
addresses can be set per system. The address must be a valid IPv6 address,
specified in hexadecimal using 16-bit values between colons.
• Prefix — Indicates the length of the IPv6 prefix. The length is a decimal value
that indicates how many of the high-order contiguous bits of the address
comprise the prefix (the network portion of the address). The possible field
values are 5-128.
• DAD Status — Displays the current DAD status. The possible field values are:

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
