Configuring IP Information
IP Addressing
Cisco Small Business SFE/SGE Managed Switches Administration Guide 219
7
STEP 1 Click System > System Management > IP Addressing > ARP. The ARP Page opens:
ARP Page
The
ARP Page contains the following fields.
• ARP Entry Age Out — Defines the amount of time (seconds) that pass between
ARP requests about an ARP table entry. After this period, the entry is deleted
from the table. The range is 1 - 40000000, where zero indicates that entries are
never cleared from the cache. The default value is 60,000 seconds.
• Clear ARP Table Entries— Indicates the type of ARP entries that are cleared on
all devices. The possible values are:
- All — All ARP entries are cleared.
- Dynamic — Only dynamic ARP entries are cleared.
- Static — Only static ARP entries are cleared.
- None — ARP Entries are not cleared.
ARP Table
• Interface — Indicates the interface for which the ARP parameters are defined.
• IP Address — Indicates the station IP address, which is associated with the
MAC address.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
