Configuring IP Information
IP Addressing
Cisco Small Business SFE/SGE Managed Switches Administration Guide 220
7
• MAC Address — Indicates the station MAC address, which is associated in the
ARP table with the IP address.
• Status — Indicates the ARP Table entry status. Possible field values are:
- Dynamic — Indicates the ARP entry was learned dynamically.
- Static — Indicates the ARP entry is a static entry.
STEP 2 Click Add. The Add ARP Page opens:
Add ARP Page
The
Add ARP Page contains the following fields:
• Supported IP Format — Indicates the IP address format supported by the host.
The possible field values are:
- Version 4 — Indicates that the host supports IPv4 addresses only.
• VLAN — Indicates the ARP-enabled interface.
• IPv4 Address — Indicates the station IP address, which is associated with the
MAC address filled in below.
• MAC Address — Indicates the station MAC address, which is associated in the
ARP table with the IP address.
STEP 3 Define the relevant fields.
STEP 4 Click Apply. The ARP Settings are defined, and the device is updated.
Modifying ARP Settings
STEP 1 Click System > System Management > IP Addressing > ARP. The ARP Page opens:
STEP 2 Click the Edit button. The Edit ARP Page opens:

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
