Configuring IP Information
IP Addressing
Cisco Small Business SFE/SGE Managed Switches Administration Guide 223
7
Add IP Static Route Page
In addition to the fields in the
IP Static Routing Page,
the
Add IP Static Route Page
contains the following additional fields:
• Destination IP Address — Defines the destination IP address.
• Network Mask — Defines the currently configured IP address mask.
• Prefix Length —Defines the IP route prefix for the destination IP. The prefix
length must be preceded by a forward slash (/).
• Next Hop — Defines the next hop’s IP address or IP alias on the route.
• Route Type —Defines the route type. The possible field values are:
-
Reject
— Rejects the route, and stops routing to the destination network
via all gateways.
-
Remote
— Indicates the route is a remote path.
• Metric(1-255)— Defines the administrative distance to the next hop. The range
is 1-255. The default value is 1.
STEP 3 Define the relevant fields.
STEP 4 Click Apply. The IP Static route is added, and device is updated.
