Configuring SNMP
Configuring SNMP Security
Cisco Small Business SFE/SGE Managed Switches Administration Guide 313
12
- Authentication — Authenticates SNMP messages, and ensures the
SNMP messages origin is authenticated.
- Privacy — Encrypts SNMP message.
• Operation — Defines the group access right, which are per view. The possible
field values are:
- Default — Defines the default group access rights.
- DefaultSuper — Defines the default group access rights for
administrator.
STEP 3 Define the relevant fields.
STEP 4 Click Apply. The SNMP Community is defined, and the device is updated.
Modifying SNMP Group Profile Settings
STEP 1 Click System > SNMP > Security > Groups. The SNMP Groups Page opens:
STEP 2 Click the Edit Button. The Edit SNMP Group Profile Page opens:
Edit SNMP Group Profile Page
The
Edit SNMP Group Profile Page contains the following fields:
• Group Name — Displays the user-defined group to which access control rules
are applied. The field range is up to 30 characters.
• Security Model — Defines the SNMP version attached to the group. The
possible field values are:
- SNMPv1 — SNMPv1 is defined for the group.
- SNMPv2 — SNMPv2 is defined for the group.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
