Configuring SNMP
Configuring SNMP Security
Cisco Small Business SFE/SGE Managed Switches Administration Guide 312
12
• Operation — Defines the group access right, which are per view. The possible
field values are:
- Read — The management access is restricted to read-only, and
changes cannot be made to the assigned SNMP view.
- Write — The management access is read-write and changes can be
made to the assigned SNMP view.
- Notify — Sends traps for the assigned SNMP view.
STEP 2 Click the Add button. The Add SNMP Group Profile Page opens:
Add SNMP Group Profile Page
The
Add SNMP Group Profile Page allows network managers to define new
SNMP Group profiles. The
Add SNMP Group Profile Page contains the following
fields:
• Group Name — Defines the user-defined group to which privileges are
applied. The field range is up to 30 characters.
• Security Model — Defines the SNMP version attached to the group. The
possible field values are:
- SNMPv1 — SNMPv1 is defined for the group.
- SNMPv2 — SNMPv2 is defined for the group.
- SNMPv3 — SNMPv3 is defined for the group.
• Security Level — Defines the security level attached to the group. Security
levels apply to SNMPv3 only.
- No Authentication — Neither the Authentication nor the Privacy security
levels are assigned to the group.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
