Configuring System Time
Defining SNTP Settings
Cisco Small Business SFE/SGE Managed Switches Administration Guide 38
3
- Unknown — The progress of the SNTP information currently being sent
is unknown. For example, the device is currently trying to locate an
interface.
• Status — The operating SNTP server status. The possible field values are:
- Up — The SNTP server is currently operating normally.
- Down — Indicates that a SNTP server is currently not available. For
example, the SNTP server is currently not connected or is currently
down.
- Unknown — Indicates that the device (sntp client) is currently looking for
sntp server.
• Last Response — Indicates the last time a response was received from the
SNTP server.
• Offset — Indicates the difference in minutes between DST and the local
standard time.The default time is 60 minutes.
• Delay — Indicates the amount of time it takes to reach the SNTP server.
STEP 2 Click the Add button. The Add SNTP Server Page opens:
Add SNTP Server Page
The
Add SNTP Server Page contains the following fields:
• Supported IP Format — Provides the supported IP format: Version 6 or
Version 4.
- IPv6 Address Type — Indicates the type of IP Address: Link Local or
Global.
• SNTP Server — The SNTP server’s IP address.
• Enable Poll Interval — Select whether or not the device polls the selected
SNTP server for system time information.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
