Dell PowerConnect 3524

QoS Commands 309
Example
The following example displays the DSCP port-queue map.
The following table describes the significant fields shown above.
Console> show qos map
Dscp-queue map:
d1 : d2 0 1 2 3 4 5 6 7 8 9
------------------------------------
0 : 01 01 01 01 01 01 01 01 01 01
1 : 01 01 01 01 01 01 02 02 02 02
2 : 02 02 02 02 02 02 02 02 02 02
3 : 02 02 03 03 03 03 03 03 03 03
4 : 03 03 03 03 03 03 03 03 04 04
5 : 04 04 04 04 04 04 04 04 04 04
6 : 04 04 04 04
Column Description
d1 Decimal Bit 1 of DSCP
d2 Decimal Bit 2 of DSCP
01 - 04 Queue numbers
