480 VLAN Commands
Command Mode
Interface Configuration (Ethernet, port-channel) mode.
User Guidelines
Use this command to override the FDB decision, and forward the packet to the uplink. Please note that
the packet is still subject to all filtering decisions.
The following example overrides the FDB decision, and sends all the Unicast, Multicast and Broadcast
traffic to specified ethernet port.
map protocol protocols-group
The map protocol protocols-group VLAN Configuration mode command maps a protocol to a protocol
group. Protocol groups are used for protocol-based VLAN assignment. Use the no form of this command
to delete a protocol from a group.
Syntax
• map protocol protocol [ encapsulation ] protocols-group group
• no map protocol protocol encapsulation
• protocol — The protocol is a 16 or 40 bits protocol number or one of the following names, ip, ipx
or arp . The protocol number is in Hex format (Range: 0600 - FFFF).
•
encapsulation — One of the following values: ethernet or protocols-group . If no option is
indicated the default is
ethernet .
•
group — Protocol group number. (Range: 1 - 2147483647)
Default Configuration
This command has no default configuration.
Command Mode
VLAN Configuration mode.
User Guidelines
There are no user guidelines for this command.
Console(config)# interface ethernet 1/e5
Console(config-if)# switchport protected ethernet 2/g1
book.book Page 480 Thursday, December 18, 2008 7:40 PM

Dell PowerConnect 3524 Specifications

General

Throughput	9.5 Mpps
Number of queues	4
MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	No
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Input frequency	50/60 Hz
Weight (imperial)	11 lbs
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Dimensions (W x D x H) (imperial)	17.3 x 10.12 x 1.7 \
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
Gigabit Ethernet (copper) ports quantity	2
Basic switching RJ-45 Ethernet ports quantity	24
Product color	Black
Power source	AC
Input voltage	100 - 240 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	5000 g
