376 Spanning-Tree Commands
Path Cost 20000
Root Port 1 (1/e1)
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
Bridge
ID
Priority 36864
Address 00:02:4b:29:7a:00
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
Interfaces
Name State Prio.Nbr Cost Sts Role PortFast Type
---- ------- -------- ----- --- ---- -------- ----------
1/e1 Enabled 128.1 20000 FWD Root No P2p (RSTP)
1/e2 Enabled 128.2 20000 FWD Desg No Shared (STP)
1/e3 Disabled 128.3 20000 - - - -
1/e4 Enabled 128.4 20000 BLK ALTN No Shared (STP)
1/e5 Enabled 128.5 20000 DIS - - -
Console# show spanning-tree
Spanning tree enabled mode RSTP
Default port cost method: long
Root ID Priority 36864
Address 00:02:4b:29:7a:00
This switch is the root.
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
