384 Spanning-Tree Commands
Bridge ID Priority 32768
Address 00:02:4b:29:7a:0
0
Interfaces
Name State Prio.Nbr Cost Sts Role PortFast Type
---- ------- -------- ----- --- ---- -------- ----------
1/e1 Enabled 128.1 20000 FWD Boun No P2p Bound (RSTP)
1/e2 Enabled 128.2 20000 FWD Boun No Shared Bound
(STP)
1/e3 Enabled 128.3 20000 BLK Altn No P2p
1/e4 Enabled 128.4 20000 FWD Desg No P2p
Console# show spanning-tree detail
Spanning tree enabled mode MSTP
Default port cost method: long
###### MST 0 Vlans Mapped: 1-9, 21-4094
CST Root ID Priority 32768
Address 00:01:42:97:e0:00
Path Cost 20000
Root Port 1 (1/e1)
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
IST Master ID Priority 32768
Address 00:02:4b:29:7a:0
0
This switch is the IST master.
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
