388 Spanning-Tree Commands
Number of transitions to forwarding state: 1
BPDU: sent 2, received 170638
Console# show spanning-tree
Spanning tree enabled mode MSTP
Default port cost method: long
###### MST 0 Vlans Mapped: 1-9, 21-4094
CST Root ID Priority 32768
Address 00:01:42:97:e0:00
Path Cost 20000
Root Port 1 (1/e1)
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
IST Master ID Priority 32768
Address 00:02:4b:19:7a:0
0
Path Cost 10000
Rem hops 19
Bridge
ID
Priority 32768
Address 00:02:4b:29:7a:0
0
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
Max hops 20
Console# show spanning-tree
book.book Page 388 Thursday, December 18, 2008 7:40 PM
