AH500 Hardware and Operation Manual
2-92
Terminal Description
Response
characteristic
Maximum input
Current
Voltage
X0.3+, and
X0.3-
 The terminals are the RESET input
terminals for counter 0~counter 5.
 X0.0+ and X0.0- are for counter 0. X0.1+
and X0.1- are for counter 1. X0.2+ and
X0.2- are for counter 2 and counter 4.
X0.3+ and X0.3- are for counter 3 and
counter 5.
 High-speed comparison and catch: The
terminals can function as trigger signals for
high-speed catches.
X0.8+, X0.8-,
X0.9+, and
X0.9-
1. They are differential input terminals.
2. The functions of the terminals:
 Motion control: The terminals are for a manual
pulse generator.
 High-speed count:
 The terminals are for counter 0.
 X0.8+ and X0.8- are the A-phase input
terminals for counter 0. X0.9+ and X0.9-
are the B-phase input terminals for
counter 0.
 High-speed comparison and catch: The
terminals can function as trigger signals for
high-speed catches.

Interrupt input terminals
200 kHz 15 mA 5~24 V
X0.10+,
X0.10-,
X0.11+,
X0.11-,
X0.12+,
X0.12-,
X0.13+,
X0.13,
X0.14+,
X0.14-,
X0.15+, and
X0.15-
1. They are differential input terminals.
2. The functions of the terminals:
 Motion Control:
Axis 1~6 Dog point pulse input, applicable for
single-axis input motion controls.
 High-speed count:
 The terminals are for counter 1~counter
5.
 X0.10+ and X0.10- are the A-phase input
terminals for counter 1. X0.12+ and
X0.12- are the A-phase input temrinals for
counter 2 and counter 4. X0.14+ and
X0.14- are the A-phase input terminals for
counter 3 and counter 5.
 X0.11+ and X0.11- are the B-phase input
terminals for counter 1. X0.13+ and
X0.13- are the B-phase input terminals
for counter 2 and counter 4. X0.15+ and
X0.15- are the B-phase input terminals
for counter 3 and counter 5.
 High-speed comparison and catch: The
terminals can function as trigger signals for
high-speed catches.
 Interrupt input terminals
200 kHz 15 mA 5~24 V
Y0.8, Y0.9,
Y0.10, and
Y0.11
1. The high-speed pulse output temrinals are
transistors whose collectors are open collectors.
2. The function of the terminals:
 High-speed comparison and catch: The
terminals can function as high-speed
comparison output temrinals.
200 kHz 15 mA 24 V
