AH500 Hardware and Operation Manual
6-26
(5) Set the parameters in the Driver Properties window, and then click OK.
Type a driver name in the Driver Name box.
Select USB (Virtual COM) in the Type drop-down list box in the Connection Setup section.
Select a communication port in the COM Port drop-down list box. If the first two steps are complete,
the PLC which is connected and its communication port will be displayed in the COM Port drop-down
list box.
Users can select the number of times the sending of a command is retried if a connection error occurs
in the Connect Retries box, and select an interval of retrying the sending of a command in the
Connection Time-Out box.
(6) Check if the Status of Driver is OK, if it is ok, you can close the window. COMMGR is still running in the
Windows.
