AH500 Hardware and Operation Manual
12-18
Error
Code
Description Solution
16#E280
The network module IP of the control
mode CPU on the main backplane slot 0
cannot be detected.
1. Make sure the network cables of the network
modules on the main backplane slot 0 are
well-connected both on the control mode CPU
and standby mode CPU.
2. If the network modules network cable of the
control mode CPU on the main backplane slot 0
is connected to the network port 1, the network
modules network cable of the standby mode
CPU on the main backplane slot 0 must be
connected to the network port 1 as well.
3. Mare sure the network modules of the control
mode CPU and the standby mode CPU on the
main backplane slot 0 are on the same physical
network.
16#E281
The network module IP of the control
mode CPU on the main backplane slot 1
cannot be detected.
1. Make sure the network cables of the network
modules on the main backplane slot 1 are
well-connected both on the control mode CPU
and standby mode CPU.
2. If the network modules network cable of the
control mode CPU on the main backplane slot 0
is connected to the network port 1, the network
modules network cable of the standby mode
CPU on the main backplane slot 1 must be
connected to the network port 1 as well.
3. Mare sure the network modules of the control
mode CPU and the standby mode CPU on the
main backplane slot 1 are on the same physical
network.
16#E282
The network module IP of the control
mode CPU on the main backplane slot 2
cannot be detected.
1. Make sure the network cables of the network
modules on the main backplane slot 2 are
well-connected both on the control mode CPU
and standby mode CPU.
2. If the network modules network cable of the
control mode CPU on the main backplane slot 2
is connected to the network port 1, the network
modules network cable of the standby mode
CPU on the main backplane slot 2 must be
connected to the network port 1 as well.
3. Mare sure the network modules of the control
mode CPU and the standby mode CPU on the
main backplane slot 2 are on the same physical
network.
