Dynapac MF2500CS - Bypass function travel drive pump Tier3, Tier4 F

C 11 35
Bypass function travel drive pump Tier3, Tier4F
A
There is a shuttle valve (6) on each of the travel drive pumps (5).
To activate the bypass function:
- unscrew the shuttle valve (7) with an Allen key (SW8), turning counterclockwise
as far as it will go (8).
m
On completion of the towing process, restore the initial status.
5
8
7
6
