6.5 Instructive symbols, prohibitive symbols, warning symbols
No.
Pictogram Meaning
50 - Wear ear protectors
51 - Do not spray the area or component with water!
52 - Warning on dangers posed by batteries!
53 - First aid kit
54
(O)
- Escape route
A
In the event of a vehicle malfunction,
the raised control platform can be left via this route.
(Emergency steps + ladder)
55
(O)
- Not an escape route
A
In the event of a vehicle malfunction, this route may
not be used to leave the raised control platform.
