F 32 16
Move scraper into working position before starting work,
carry out function test/adjust distance
- Move scraper into working position:
- Tighten the scraper at the T-bolts (A) so that the lower edge of the two scrapers
is flush with the lower edge of the holders (B).
- First adjust the rear scraper in the travel direction:
- Tighten the T-bolts (A) evenly at the right and left of the machine, possibly count-
ing the turns.
