D 41 28
Distance display
When the distance control is activated, the LED beacon at the back of the control plat-
form shows the operator of the following paver the current distance between feeder
and paver finisher together with other status displays:
Meaning Symbol in the display
OFF
A
Travel by drive lever
Stop for paver finisher
A
Feeder is at a standstill.
Heed warning!
A
Distance Assist after 10 sec-
onds standstill in "standby".
Release by pressing the
"Distance Assist" button
on the operating panel
(LED in the button flashes).
Restart for paver finisher
A
Release for start up
Distance outside range
>2.5m
Very large distance
max. 2.5m
Large distance
max 2.0m
Small distance
max 1.5m
