C 11 12
4 Securing the load
4.1 Securing at the front
m
Diagonal lashing must be performed to secure the vehicle in the direction of travel.
The lashing points on the vehicle and on the low-bed trailer must be used. The lashing
equipment must be installed as shown.
m
The vertical angle "a" must not be less or more than the 19° - 36° ranges!
The horizontal angle "ß" must not be less or more than the 6° - 39° ranges!
