D 41 25
1.4 Starting for feeder operation
Set the following switches, levers and controls to the specified positions when the
paver finisher has been filled with sufficient material:
- Push the drive lever (13) all the way to the front and start driving.
Regulated by material scanning, the main conveyor belt and cross conveyor (o)
are started up.
- As soon as the desired distance between the paver finisher and feeder has been
reached, activate distance control (59)/(60) (LED "ON")
- Adjust the distance with buttons (61)/(62).
f
During feeder operation without distance control (o), always adjust the vehicle speed
to the paver finisher's speed! Always equip and operate the paver finisher with the
"Emergency stop during feeder operation" function!
- Observe the distribution of the material and adjust the limit switch if necessary.
Item Travelling direction Position
63 Filling function LED "OFF"
33 Travel drive fast/slow LED "OFF"
15 Travel drive preselector Mark 6-7
51
Main conveyor belt + slewing convey-
or belt (o)
"AUTO"
49/50
Output control
Main conveyor belt + slewing convey-
or belt (o)
adapted to the paving situation
