D 30 25
Lane clearer (o)
A swivelling lane clearer (1), which de-
flects small obstacles away to one side,
is located in front of both drive units.
A
The lane clearers should only be swiv-
elled down in operating mode.
Swivelling the lane clearers:
- Swivel the lane clearers (1) up and se-
cure in the uppermost position with
a hook (2).
m
To avoid collisions in operating mode,
the lane clearer may only be lowered so
that a space of a few mm is available be-
tween the ground and the blade (3).
Fire extinguisher (o)
A
The machine personnel must be famil-
iarised with operation of the fire extin-
guisher (1).
A
Observe the inspection interval for
the fire extinguisher!
