F 95 8
Conveyor remixer
Checking the scraper
for function and wear (4)
A scraper (A) is available to protect the
conveyor belt from asphalt residues dur-
ing and after work and to prevent con-
tamination and wear.
The scraper is fitted with several blades
that scrape off material residues.
A
If the scraper blades are worn, they must
be replaced as complete sets on the en
-
tire scraper.
A
The correct spacing between the scrap-
er blade and the conveyor is 10 mm.
Adjust if necessary:
- Slightly loosen the nuts (B) along
the whole length of the scraper.
- Unfasten the lock nuts on the
two adjusting screws (C).
- Turn the screws (C) to adjust
the height.
- Then tighten the lock nuts of the ad-
justing screws (C) and nuts (B) again
properly.
