10 Towing
f
Heed all regulations and apply all safety measures applicable for towing heavy con-
struction machines.
m
The towing vehicle must be capable of securing the feeder even on slopes.
Use only approved tow bars!
If necessary, reduce the feeder to its basic width.
A
A hand pump (1) is located in the engine compartment (left side); it must be actuated
to be able to tow the vehicle.
Pressure for releasing the traction system brakes is built up with the hand pump.
- Release lock nut (2), screw threaded
dowel (3) into pump as far as possible
and secure with lock nut.
- Push knob (3a) into the valve body.
While pumping (next step), check
that the knob remains in the pressed
position.
- Actuate lever (4) of hand pump until
sufficient pressure has been built up
and traction system brakes have been
released.
m
On completion of the towing process,
restore the initial status.
m
Only release the traction system brakes
when the vehicle has been sufficiently
secured to prevent it rolling away acci-
dentally or is already properly connected
to the towing vehicle.
