D 30 30
Distance display
When the distance control is activated,
the LED beacon (1) at the back of the
control platform shows the operator of
the following paver the current distance
between feeder and paver finisher to-
gether with other status displays.
A
Inform the paver finisher operator about
the meaning of the following displays.
Meaning Symbol in the display
OFF
A
Travel by drive lever
Stop for paver finisher
A
Feeder is at a standstill.
Heed warning!
A
Distance Assist after 10 sec-
onds standstill in "standby".
Release by pressing the
"Distance Assist" button
on the operating panel
(LED in the button flashes).
Restart for paver finisher
A
Release for start up
Distance outside range
>2.5m
Very large distance
max. 2.5m
