Mount stone guard
A
Two different types of stone guard are available, depending on the type of operation:
- stone guard for large paver finisher / bucket feed (t) (cope of supply)
- stone guard for small paver finisher feed (o).
A
The material chute is included in the scope of supply of the slewing belt.
Fit stone guard / material chute (1):
- Mount the holders (2) of the premounted stone guard / material chute (1)
to the housing of the conveyor belt drive on both sides of the vehicle.
m
Worn or damaged parts of the stone guard or material chute must
be replaced immediately.
Danger from material being flung out
During operation, particularly when conveying loose mate-
rial (e.g. gravel), the scraper can fling stones or particles
out at the back of the vehicle (opposite to the direction
of travel)!
- When operating without the slewing belt, the main con-
veyor may only be operated with fitted stone guard.
- The slewing belt may only be operated with fitted
stone guard:
when retrofitting a slewing belt, the stone guard from
the main conveyor must be dismantled and fitted to
the slewing belt.
In this case, the material chute must be fitted to the main
conveyor belt.
- Do not enter the danger zone.
- Comply with all further information in these instructions
and in the safety manual.
