Dynapac MF2500CS - Rotary beacon (o)

D 30 26
Rotary beacon (o)
m
The function of the rotary beacon must
be checked daily before starting work.
- Place the rotary beacon (1) onto the
plug-in contact and secure with a wing
bolt (2).
- Extend the rotary beacon with tube (3)
to the desired height and secure with
the clamping bolt (4).
- Activate the function on the operat-
ing panel as necessary.
- On completion of work, release the
bolt (5) and swivel the bracket 90°.
A
The rotary beacon is easy to remove
and should be stored securely at
the end of work.
(o)
1
2
3
4
5
