F 33 11
Check conveyor belt frame for
deposits, clean (2)
f
Perform inspection, cleaning and repairs
only whilst the drive engine is stationary!
A
Material deposits in the frame of the conveyor belt can cause subsequent damage!
A
There is a tarpaulin (A) underneath the frame and maintenance flaps and
at
the rear reversal (B).
- Loosen tarpaulin (A) as far as necessary (snap hook).
- Open maintenance flaps (B) (wing bolts).
- Remove material deposits, possibly spray the surfaces with separator fluid.
- Then put the tarpaulin back in the correct position and close all maintenance flaps.
