Dynapac MF2500CS - 11 Safely parking the vehicle

C 11 38
11 Safely parking the vehicle
m
When the feeder is parked in a location accessible to the public, it must be secured
in such a way that unauthorised persons or playing children cannot damage
the vehicle.
- Move the operating panel (1) to the transportation position and lock properly
in position.
- Move the seat console (2) to the transportation position and lock properly
in position.
- Close the hopper and set the hopper transport safeguards (3) on both sides.
- Lower slewing belt (o) to lowest position.
- Lower height-adjustable (o) conveyor belt to lowest position.
- The conveyor belt must stand on all standing legs (4). The standing legs must be
secured in lowered position with the corresponding retaining pins (5).
- Lower control platform to lowest position (o).
- Switch off the vehicle, remove the ignition key.
- Attach and secure the protective hood (6) to the operating panel.
7
1
6
2
3
8
4
5
