3.5 Preparing the vehicle
After the vehicle has been positioned on the low-bed trailer, the following prepara-
tions must be carried out:
- Move the operating panel (1) to the transportation position and lock properly in position.
- Move the seat console (2) to the transportation position and lock properly in position.
- Close the hopper and set the hopper transport safeguards (3) on both sides.
- Lower slewing belt (o) to lowest position.
- Lower height-adjustable (o) conveyor belt to lowest position.
- Lower control platform to lowest position (o).
- Switch the vehicle off.
- Insert the retaining pin (4) at the swivel arm (o).
- Attach and secure the protective hood (5) to the operating panel.
- Lower the roof and set the latches (6) properly on both sides
(see Section entitled "Protective roof").
- Fold up the folding step (7) on both sides.
6
3
1
5
2
7
4
