B 24
5.18 Hydraulic system
5.19 Material compartment (hopper)
5.20 Material transfer
5.21 Electrical system
5.22 Permissible temperature ranges
Pressure generation
Hydraulic pumps via distribution gear
(directly connected to the engine)
Pressure distribution
Hydraulic circuits for:
- Travel drive
- Conveyor belt
- Operating functions
-Fan
Hydraulic oil reservoir - volume (See chapter F)
Volume
Approx. 6.5 m
3
= approx. 13.0 t
Minimum inlet height, centre 580 mm
Hopper width, outside, open 3335
Type Rubber conveyor belt
Width, main conveyor belt 1200 mm
Width, slewing conveyor belt 1380 mm
Drive Hydrostatic, continuously controllable
Conveying volume controller Fully automatic via configurable switching points
On-board voltage 24 V
Batteries 2 x 12 V, 100 Ah
Operation -5°C / +45°C
Storage -5°C / +45°C
