F 32 10
Conveyor belt - screw connections
m
Incorrectly installed conveyor belt bolts
can lead to severe damage to the entire
conveyor belt.
m
Visually and mechanically check that
the screw connections are fastened cor-
rectly.
- Conveyor belt - conveyor belt web (D)
(flat-headed bolts):
- The bolt head must be positioned
plane with the rubber surface and
may be recessed by max. 1 mm.
- Drive chain - conveyor belt (E) (hexag-
onal bolts):
- The bolts must not be tightened
too tightly.
m
Self-locking nuts must be replaced and
must not be retightened!
