C 11 4
Preparations
Operation Buttons
- Deactivating the function lock
- Activate set-up mode.
- Lower control platform.(o)
- Close the hopper lids.
- Engage both hopper transport safeguards.
- Fully extend drive unit frame cylinders.
- Raise slewing belt.(o)
- Bring slewing belt into the centre
position.(o)
- Lower main conveyor belt (o).
A
* Heed note
- Insert the retaining pin at the swivel
arm.(o)
- Deactivate set-up mode.
