E 7
Preparing the slewing belt
A
Four lifting eyes (4,5) are provided for lifting the conveyor belt with a crane.
- The conveyor belt must be cleaned, all material deposits removed and all mainte-
nance flaps closed correctly.
m
The retaining bolt (6) must be inserted at the swivel arm.
- Remove the bolts (7) on both sides.
- Attach lifting gear to the four attachment points (4, 5).
