F 95 12
Cutting wedge - check wear (8)
A
The cutting wedge (A) is on the top of the
remixer unit. The part is located directly
in the material flow with the risk of great-
er wear and tear.
- Remove the spring cotter pin and re-
taining bolt (B) to pull the cutting
wedge out of the remixer unit.
- The blades (C) must be replaced
if they are worn.
