Installation and operation
- Fasten the illuminated balloon (1) to the holding tube (2) and pull the clamping
lever (3) tight.
- With one hand on the handle flagged in green (4), pull down hard to open the bal-
loon before putting it into operation.
When the balloon has been pulled down completely up to the stop, a safety
catch (5) folds out of the guide rod.
- Set the telescopic tube to the desired height using the clamping lever (6).
- Guide the holding tube (7) into the pre-mounted holder (8) and tighten the clamping
screws correctly to fix the holding tube.
- Once the illuminated balloon is completely mounted and secured, connect the
plug
(9) of the illuminated balloon in the corresponding sockets (10).
m
Route the supply lines so as to rule out any risk of stumbling or damage to the lines.
A
Engagement is carried out on the operating panel.
A
The holding tube most be removed during transport or to lower the roof!
Danger due to electric shock
Electric shock can cause severe or fatal injuries
- The Powermoon must always be completely unpacked,
assembled and aligned before it is connected to the
power grid and switched on!
Danger of squeezing!
Fingers or hands can get clamped between the bracket and
the holding tube!
- Caution when inserting the holding tube!
