Dynapac MF2500CS - 5.11 Weights (all weights in t); 5.12 Capacity data; 5.13 Conveyor belt speeds

B 22
5.11 Weights (all weights in t)
5.12 Capacity data
5.13 Conveyor belt speeds
Feeder MF2500CS approx. 20.0
Feeder MF2500CM approx. 21.0
Feeder MF2500CS,
with slewing belt SW5500
approx. 24.5
Feeder MF2500CS,
with slewing belt SW6500
approx. 24.6
With filled hopper
additionally max.
approx. 12.0
Slewing belt SW5500 approx. 4.5
Slewing belt SW6500 approx. 4.6
With additional hopper remixer approx. 0.5
With additional conveyor remixer approx. 0.5
Transport speed 0 - 4 km/h
Operating speed 0 - 25 m/min
Conveying rate, solo feeder 4000 t/h
Conveying rate
with conveyor remixer
1000 t/h
Conveying rate with
slewing belt SW5500 (o)
2000 t/h
Conveying rate with
slewing belt SW6500 (o)
1500 t/h
Main belt Slewing belt
MF2500CS/CM 100.0 rpm
+ SW5500 51.0 rpm 85.0 rpm
+ SW6000 37.5 rpm 85.0 rpm
+Imix & SW 25.0 rpm (85.0 rpm)
Remotelock 10.0 rpm 10 rpm
