C 11 10
3.4 Loading
m
Pay attention to load distribution during loading!
On some vehicles, the kingpin load is too low so that the load has to be positioned
further to the back of the vehicle.
Always observe the specifications regarding load distribution for the vehicle and the
centre of gravity of the vehicle.
m
The overall height (X) of 4 m must not be exceeded!
m
The overall width (X) of 2.55m must not be exceeded!
X
X
MF2500CS - standard
MF2500CS - slewing belt
