D 11 21
Item Designation Brief description
34 Close hopper left
Pushbutton function:
- To close the left half of the hopper
A
Separate actuation (o):
Is required when paving in spaces where there is only
limited space at one side or when obstacles obstruct
truck unloading.
f
On actuation, heed danger zones of moving parts of
the vehicle!
35 Close hopper right
Pushbutton function:
- To close the right half of the hopper
A
Separate actuation (o):
Is required when paving in spaces where there is only
limited space at one side or when obstacles obstruct
truck unloading.
f
On actuation, heed danger zones of moving parts of
the vehicle!
36 Open hopper left
Pushbutton function:
- To open the left half of the hopper
A
If the hoppers are hydraulically actuated at the same ti-
me, both the left and the right switch can be used for ac-
tuation.
f
On actuation, heed danger zones of moving parts of
the vehicle!
37 Open hopper right
Pushbutton function:
- To open the right half of the hopper
A
If the hoppers are hydraulically actuated at the same ti-
me, both the left and the right switch can be used for ac-
tuation.
f
On actuation, heed danger zones of moving parts of
the vehicle!
