D 11 27
Item Designation Brief description LED display
42
"Truck Assist"
AUTO mode
ON / OFF
Pushbutton function with LED feedback:
- The "Truck Assist" function runs auto-
matically.
- Switch OFF by pressing the button
again
- Press button (38) to request a truck
with material / Release for truck to
approach
(GREEN SIGNAL)
A
The truck is detected by a laser sensor at
a distance of 6 m between the paver and
the material truck.
(GREEN SIGNAL, flashing)
A
The flashing frequency of the display in-
creases with decreasing distance bet-
ween paver and material truck.
- On reaching the preset minimum dis-
tance, the signal changes over to
"STOP". (RED SIGNAL)
A
The minimum distance is adjusted in the
display settings.
A
The other signals have to be triggered
by hand.
