Dynapac MF2500CS - Page 143

D 11 29
m
When fitted with SW6500:
Every time after restarting the vehicle, the main conveyor has to be moved into its up-
per end position when starting up the conveying function for the first time or when ac-
tuating functions (43-46) / (131-134)!
Function buttons (47) and (48) are then deactivated until the next restart.
Item Designation Brief description
43
Raise
slewing belt (o)
Pushbutton function:
- To raise the slewing belt.
A
This function is not used in vehicle configurations wit-
hout a slewing belt.
f
On actuation, heed danger zones of moving parts of
the vehicle!
44
Lower
slewing belt (o)
Pushbutton function:
- To lower the slewing belt.
A
This function is not used in vehicle configurations wit-
hout a slewing belt.
f
On actuation, heed danger zones of moving parts of
the vehicle!
45
Slew slewing belt
to the left (o)
Pushbutton function:
- For slewing the conveyor belt to the left.
A
This function is not used in vehicle configurations wit-
hout a slewing belt.
f
On actuation, heed danger zones of moving parts of
the vehicle!
46
Slew slewing belt
to the right (o)
Pushbutton function:
- For slewing the conveyor belt to the right.
A
This function is not used in vehicle configurations wit-
hout a slewing belt.
f
On actuation, heed danger zones of moving parts of
the vehicle!
