D 11 31
m
When fitted with SW5500:
To operate the main conveyor, it must be raised to its upper position and must
stay there!
m
When fitted with SW6500:
Every time after restarting the vehicle, the main conveyor has to be moved into its up-
per end position when starting up the conveying function for the first time or when ac-
tuating functions (43-46) / (131-134)!
Function buttons (47) and (48) are then deactivated until the next restart.
Item Designation Brief description
47
Raise main
conveyor belt
Pushbutton function:
- To raise the main conveyor belt.
m
When fitted with SW6500:
f
On actuation, heed danger zones of moving parts of
the vehicle!
48
Lower main
conveyor belt
Pushbutton function:
- To lower the main conveyor belt.
f
On actuation, heed danger zones of moving parts of
the vehicle!
