D 11 35
Item Designation Brief description
51
Main conveyor belt
+ slewing conveyor
belt (o) -
"AUTO"
Button with detent switch function and LED feedback:
- The conveying function is switched on when the drive
lever is swivelled out and is continuously controlled
via the material limit switches.
- Switch OFF by pressing the button again
A
The function is shut off by pressing the EMERGENCY
STOP button or restarting the vehicle.
A
The main function switch locks the conveying function.
f
On actuation, heed danger zones of moving parts of
the vehicle!
52
Main conveyor belt
+ slewing conveyor
belt (o) -
"MANUAL"
Slow speed
Button with detent switch function and LED feedback:
- The conveying function is switched on continuously at
half of the delivery rate, without material control via
the limit switches.
- Switch OFF by pressing the button again
A
The function is shut off by pressing the EMERGENCY
STOP button or restarting the vehicle.
A
The main function switch locks the conveying function.
f
On actuation, heed danger zones of moving parts of
the vehicle!
