D 11 39
Item Designation Brief description
55
Save / approach
slewing position
left
Pushbutton function with LED feedback:
- Press and hold button:
the current position (slewing angle and slewing
height) is saved.
- Press button briefly: slewing released. (LED flashes).
Press button (57) to start slewing.
A
Slewing can only begin while the LED is flashing!
A
It is not possible to save a position that is further to the
right than the position saved with button (56).
f
On actuation, heed danger zones of moving parts of
the vehicle!
56
Save / approach
slewing position
right
Pushbutton function with LED feedback:
- Press and hold button:
the current position (slewing angle and slewing
height) is saved.
- Press button briefly: slewing released. (LED flashes).
Press button (57) to start slewing.
A
Slewing can only begin while the LED is flashing!
A
It is not possible to save a position that is further to the
right than the position saved with button (56).
f
On actuation, heed danger zones of moving parts of
the vehicle!
57
Approach slewing
position
Pushbutton function with LED feedback:
- Preselect button (55) / (56) + hold button to approach
the saved slewing position on the left or right.
A
Approach slewing position: LED flashes
Slewing position reached: LED on
f
On actuation, heed danger zones of moving parts of
the vehicle!
58 Not used
